silicable style 5335
SILICABLE style 5335 Mica Wire
Description
Name:High Temperature Resistance Wire
Model:AWM5335
Size:22~4/0AWG
Feature
Ratings Voltage:600V
Rated Temperature: 450℃
Structure
Conductor:Stranded Nickel Copper, Nickel
Insulation:Mica Tape ,Fiberglass Braid With High Temperature Finish
Standard:UL758、UL1581
Size AWG | Conductor Structure | Insulation Thickness (mm) | Braid Thickness (mm) | Diameter (mm) |
22 | 7/0.254 | 0.58 | 0.13 | 2.3±0.2 |
20 | 10/0.254 | 2.4±0.2 | ||
18 | 16/0.254 | 2.7±0.2 | ||
16 | 26/0.254 | 3.0±0.2 | ||
14 | 41/0.254 | 3.4±0.2 | ||
12 | 65/0.254 | 3.9±0.3 | ||
10 | 103/0.254 | 0.69 | 0.25 | 5.2±0.3 |
8 | 163/0.254 | 6.1±0.3 | ||
6 | 260/0.254 | 7.2±0.5 | ||
4 | 413/0.254 | 8.5±0.5 | ||
2 | 168/0.5 | 0.81 | 0.38 | 10.6±0.5 |
1 | 212/0.5 | 11.6±0.8 | ||
1/0 | 268/0.5 | 12.8±0.8 | ||
2/0 | 342/0.5 | 14.1±0.8 | ||
3/0 | 430/0.5 | 15.5±0.8 | ||
4/0 | 538/0.5 | 17.1±0.8 |
