80C 300V UL20233PVC Insulated TPU Jacket cable

CSA/CUL

AWM I A

Rated Temperature

80℃

Rated Voltage

300V

AWG

Conductor

Structure

Core

Insulation

Thickness

(mm)

Diameter

(mm)

Cabling

Diameter

(mm)

Jacket

Thickness

(mm)

Diameter

（Without Shield）

(mm)

Shield Thickness

(mm)

Diameter

(mm)

Jacket

Thickness

(mm)

Diameter

（With Shield）

(mm)

18

16/0.254

2

0.38

1.9

3.8

0.76

5.4±0.2

0.2

4.3

0.76

5.8±0.2

3

4.1

5.7±0.2

4.6

6.1±0.2

4

4.6

6.2±0.2

5.1

6.6±0.2

5

5.1

6.7±0.3

5.6

7.1±0.3

6

5.3

6.9±0.3

5.8

7.3±0.3

7

5.7

7.3±0.3

6.2

7.7±0.3

16

26/0.254

2

0.38

2.3

4.6

0.76

6.2±0.2

0.2

5.1

0.76

6.6±0.2

3

5.0

6.6±0.3

5.5

7.0±0.3

4

5.6

7.2±0.3

6.1

7.6±0.3

5

6.2

7.8±0.3

6.7

8.2±0.3

6

6.4

8.0±0.3

6.9

8.4±0.3

7

6.9

8.5±0.3

7.4

8.9±0.3

14

41/0.254

2

0.51

2.9

5.8

0.76

7.4±0.3

0.2

6.3

0.76

7.8±0.3

3

6.2

7.8±0.3

6.7

8.2±0.3

4

7.0

8.6±0.3

7.5

9.0±0.3

5

7.8

9.4±0.5

8.3

9.8±0.5

6

8.1

9.7±0.5

8.6

10.1±0.5

7

8.7

10.3±0.5

9.2

10.7±0.5
